8-Port 10/100/1000Mbps PoE switch with 2SFP

No.TW-808GP-2SFP

To fulfill the demand of High Power PoE for network applications with Gigabit transmission, TW-808GP-2SFP PoE Gigabit Ethernet Switch is an ideal solution. Each 10/100/1000Mbps port of the TW-808GP-2SFP features IEEE 802.3af and IEEE 802.3at Power over Ethernet (PoE) that combine up to 120-watt PoE budget on the whole system. All RJ45 copper interfaces of the TW-808GP-2SFP support 10/100/1000Mbps auto-negotiation for optimal speed detection through RJ45 Category 6, 5 or 5e cables. It also supports standard auto-MDI/MDI-X that can detect the type of connection to any Ethernet device without requiring special straight or crossover cables. 1 extra 1.25Gbps SFP slots can be used for uplink.

Description
Parameter
Application
Download

Complies with IEEE 802.3, 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T

8-Port 10/100/1000Mbps supports 52V DC power to PoE Powered Device

2 1.25Gbps SFP fiber interfaces

Complies with IEEE 802.3af/802.3at Power over Ethernet End-Span PSE

Up to 8 IEEE 802.3af devices powered

Supports PoE Power up to 15.4 watts for each PoE port

Up to 4 IEEE 802.3at devices powered

Supports PoE Power up to 30 watts for each PoE port

120-watt PoE budget

Auto detects powered device (PD)

Circuit protection prevents power interference between ports

Remote power feeding up to 100m

Hardware based 10/100/1000Mbps auto-negotiation and auto MDI/MDI-X

Features Store-and-Forward mode with wire-speed filtering and forwarding rates

IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation

Integrates address look-up engine, supporting 8K absolute MAC addresses

2M packet buffer

10K Jumbo frame supports at 1000Mbps duplex mode

Automatic address learning and address aging

Made of metal, desktop size and wall-mount design

Item		Description
Model		TW-808GP-2SFP
Power Supply	Power Supply Mode	AC Power
	Voltage Range	AC 100-240V
	Power Consumption	The device <5W， POE power supply <120W
Network Port Parameter	Network Ports	1～8 Ports: 10/100/1000Mbps Ethernet port, adaptive control Uplink SFP:1.25Gbps
	Transmission Distance	1~8 Ethernet Port：0~100m 1 Fiber: According to different optical fiber module
	Transmission Media	1~8 Ethernet Port：Cat5e/6 standard UTP cable， 2 SFP: LC interface optical fiber
	POE Agreement	IEEE802.3 af/at standards
	PoE Power Supply Mode	End-span method
	PoE Power Supply Wattage	Each port≤30W,Whole device<120W
Network Switch Specification	Network Standard	IEEE802.3 10BASE-T, IEEE802.3u 100BASE-TX, IEEE802.3ab 1000BASE-T
	Swap Mode	Store-and- forward
	Switch Capacity	20Gbps
	MAC Address List	8K
Status Indicators	Power Indicator Light	One power light （green）
	Optical Fiber Port Indicator	One fiber link indication light ( green), Green light keeps on when the fiber port is well connected
	PoE Indicator	1~8 PoE indicator light（yellow）
	Network Port LED	1~8 port ( green light on RJ45 jack) Keeps on when normally connected, Blinking when transceiver data
Protection Level	Surge Immunity	Level 3, executive standard：IEC61000-4-5
Protection Level	Electrostatic Protection	1a touch electric discharge: level 3 1a Air discharge: level 3 Executive standard：IEC61000-4-2
Operating Environment	Working Temperature	-10℃～55℃
	Storage Temperature	-40℃-85℃
	Humidity(non-congeal)	0~95%
Mechanical Attributes	Dimensions (LWH)	20214045MM
	Color	Black
	Weight	1.25kg
Reliability	Mean time between failures （MTBF）	＞50000h
